Flat Hook Receiver

Specifications: A: 6.25" B: 5.00" C: 6.25" D: 4.00"

Weight: 6.0 lbs., 2.7 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.75" B: 4.88" C: 6.50" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.


Weight: 10.3 lbs., 4.7 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.75" B: 4.88" C: 6.50" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.


Weight: 10.3 lbs., 4.7 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.66" B: 4.88" C: 6.50" D: 4.00"

Working Load Limit: 5,500 lbs./2500 kgs.


Weight: 9.7lbs., 4.4 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.75" B: 4.88" C: 6.50" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 10.3 lbs., 4.7 kgs.

The unique 3 bar winch reel design allows for easy strap insertion, even when strap ends are frayed or slots have ice build-up.

Specifications: A: 10.25" B: 6.50" C: 6.89" D: 3.94"

Working Load Limit: 5,000 lbs./2270 kgs.


Weight: 15.4 lbs., 7.0 kgs.

The unique 3 bar winch reel design allows for easy strap insertion, even when strap ends are frayed or slots have ice build-up.

Specifications: A: 10.25" B: 6.50" C: 6.89" D: 3.94"

Working Load Limit: 5,000 lbs./2270 kgs.

Weight:

The unique 3 bar winch reel design allows for easy strap insertion, even when strap ends are frayed or slots have ice build-up.

Specifications: A: 9.98" B: 6.54" C: 5.50" D: 4.00"

Working Load Limit: 5,000 lbs./2270 kgs.

Weight: 13.4 lbs., 6.0 kgs.

The unique 3 bar winch reel design allows for easy strap insertion, even when strap ends are frayed or slots have ice build-up.

Specifications: A: 9.98" B: 6.54" C: 5.50" D: 4.00"

Working Load Limit: 5,000 lbs./2270 kgs.


Weight: 13.4 lbs., 6.0 kgs.

Portable winches allow flexibility of winch placement along the trailer side channel.

Specifications: A: 7.75" B: 4.88" C: 5.50" D: 3.50"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 9.2 lbs., 4.2 kgs.

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (part numbers 3606,3606-12 and 3607).Weight:

Sliding winches will move easily in both directions to position on the track and then lock into place when tension is applied to the webbing. Sliding winches must be used with Kinedyne winch track (Part Numbers 3606 and 3607). All sliding winches can also be welded in place for fixed application.

Specifications: A: 7.66" B: 4.88" C: 5.98" D: 3.94"

Working Load Limit: 5,500 lbs./2500 kgs.

Weight: 9.2 lbs., 4.2 kgs.
